Boiler Quality Steel Plates / BQ Steel Plates
India’s Leading & Most Prominent Boiler Quality Plates Supplier, BQ Plates Manufacturer, Pressure Vessel Plates Exporter in India
ASTM A 516 GR. 60 / 70 Boiler Plates, IS 2002 GR. 2 Boiler Quality Steel Plates, ASTM A 516 GR. 60 / 70 Carbon Steel Plates Stockists
We at Jaydeep Steels are a full-service manufacturer and supplier of Boiler Quality Steel Plates which are very popular due to its diversity of use and longevity. It is basically proposed for utilization in welded pressure vessels where indent durability is important. We can supply cut to size boiler steel plate with both narrow and wide widths. These hot rolled boiler steel plates are made available in a variety of grades and thickness and are developed to superior quality, deliberated to hold out the internal pressure in boilers and valves.
Acknowledged for its diversity of use and longevity, this superior quality Boiler Quality Steel Plates meet the exact demands of specific industry. The high-temperature steel plates are offered by us serves as default material for pressure vessel applications.
Boiler quality steel plates are sometimes referred to as boiler grade plates with chemical composition and mechanical properties that make these BQ steel plates. Boilerplates such as steam boilers, boilers made of mild steel, pressure vessels, penstock pipes, LPG bullets, etc. Contact us today to request a free quote!
Boiler Quality Steel Plates Specification
| Thickness | 3 mm to 200 mm |
| Width | 1250mm to 4000mm |
| Length | Up to 20,000 mm |
| Certification | DUAL CERTIFICATION [SA 516 GR. 60 / 70] TRIPLE CERTIFICATION. [SA 516 GR. 60 / 65 / 70] IBR AND NON IBR |
Chemical Analysis of Boiler Quality Steel Plates
| C | Mn | P max | S max | Si max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| t < 12.5 mm |
12.5mm < t =50mm | 50mm < t ≤ 100mm | 100mm < t ≤ 200mm | t < 200 mm |
t < 12.5 mm |
t 12s.5 mm |
||||
| A516 Grade 55 | 0.18 | 0.2 | 0.22 | 0.24 | 0.26 | 06-09 | 0.55-0.98 | 0.035 | 0.035 | 0.15-0.4 |
| A516 Grade 60 | 0.21 | 0.23 | 0.25 | 0.27 | 0.27 | 06-09 | 0.85-1.2 | 0.035 | 0.035 | 0.15-0.4 |
| A516 Grade 65 | 0.24 | 0.26 | 0.28 | 0.29 | 0.29 | 0.85-1.2 | 0.85-1.2 | 0.035 | 0.035 | 0.15-0.4 |
| A516 Grade 70 | 0.27 | 0.28 | 0.3 | 0.31 | 0.31 | 0.85-1.2 | 0.85-1.2 | 0.035 | 0.035 | 0.15-0.4 |
Tensile Requirements for Boiler Quality Steel Plates
| Tensile Strength (ksi) | Tensile Strength (MPa) | Yield Strength (ksi) | Yield Strength (MPa) | Elongation in 200mm(%) | Elongation in 50mm(%) | |
|---|---|---|---|---|---|---|
| A516 Grade 55 | 55-75 | 380-515 | 30 | 205 | 23 | 27 |
| A516 Grade 60 | 60-80 | 415-550 | 32 | 220 | 21 | 25 |
| A516 Grade 65 | 65-85 | 450-585 | 35 | 240 | 19 | 23 |
| A516 Grade 70 | 70-90 | 485-620 | 38 | 260 | 17 | 21 |
Applications of Boiler Quality Steel Plates
- Boilers
- Calorifiers
- Columns
- Dished Ends
- Filters
- Flanges
- Heat exchangers
- Pipelines
- Pressure vessels
- Storage Tanks
- Valves
Boiler Quality Steel Plates - Grades
Jaydeep Steels stocks a wide range of materials and grades. Below are a list of all standard boiler quality steels plates materials and grades we stock.
Contact Jaydeep Steels Today!
Our experienced team of metal experts will get you the metal you need when you need it. Call us today for your Boiler Quality Steel Plates Needs!
