400 Monel Sheets & Plates

Home 400 Monel Sheets & Plates

400 Monel Sheets & Plates

Monel 400 Sheets, Monel UNS N04400 Plates, Monel Alloy 400 Coils, Monel 400 Circle, JIS NW 4400 Plate, Monel Werkstoff No 2.4360 Sheets, 400 Monel Hot Rolled Plates Supplier in Mumbai, India

ASTM B 127 Monel 400 Plates, Alloy 400 Sheets, ASME SB 127 Monel 400 Plate, Monel 400 Shim Sheets, 400 Monel Plate Exporter, Monel 400 Slatting Coil, Monel 400 Cold Rolled Plates, Monel 400 Sheets Manufacturer in India

Here at Jaydeep Steels, we are your one-stop source for your entire Monel 400 Sheets & Plates needs. Monel 400 (UNS N04400) is a nickel-copper alloy with excellent corrosion resistance in a wide variety of media. This offered range of Monel 400 Sheets, Plates are widely occupied in the chemical, oil and marine engineering.

Monel 400 Plates exhibits good general corrosion resistance, good weldability and moderate to high strength. It has excellent resistance to rapidly flowing brackish water or seawater which makes it more suitable to be used in a variety of applications. Alloy 400 Sheets and Plates are commonly employed in high-temperature, seawater, and acidic environments.

Most Trusted 400 Monel Plate Exporter, ASME SB127 Monel 400 Coils, 400 Monel Polished Cold Drawn Plates, Monel GOST МНЖМц 28-2,5-1,5 Strips Stockist, Manufacturer

Monel 400 Coils shows first-rate corrosion resistance and soaring strength in a variety of alkaline and acidic atmospheres and it’s particularly appropriate for reducing environments. The machinability of Monel 400 Plates is hard as it works-toughens throughout machining. Meanwhile, these Monel 400 Circles are also being offered in different sizes and shapes to our customers.

The clients can avail the Alloy 400 Sheets, Plates & Coils from us in varied specifications to cater to the diverse requirements. Contact us for a free estimate!

Monel 400 Sheets & Plates Specification

Specifications ASTM / ASME SB 127
Size 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness 0.1mm to 12 mm Thk
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

400 Monel Sheets & Plates Chemical Composition

Grade C Mn Si S Cu Fe Ni
Monel 400 0.30 max 2.00 max 0.50 max 0.024 max 28.00 – 34.00 2.50 max 63.00 min

Mechanical Properties of 400 Monel Sheets & Plates

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Monel 400 8.8 g/cm3 1350 °C (2460 °F) Psi – 80,000 , MPa – 550 Psi – 35,000 , MPa – 240 40 %

Monel 400 Sheets & Plates Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Monel 400 2.4360 N04400 NW 4400 NA 13 МНЖМц 28-2,5-1,5 NU-30M NiCu30Fe

Types of 400 Monel Sheets & Plates

Monel 400 Plain Sheets 400 Monel Shim Sheets
Monel 400 Perforated Sheet 400 Monel Galvanized Plates
Monel 400 Hot Rolled Sheets 400 Monel Cold Rolled Sheets
Monel 400 Designer Sheets 400 Monel Galvanized Sheets
Monel 400 Perforated Plates 400 Monel Chequered Plates
Monel 400 Hot Rolled Plates 400 Monel Cold Rolled Plates
400 Monel Diamond Plates Monel 400 Ring Coils
Monel 400 Foils 400 Monel Strips
ASTM B127 400 Monel Sheets ASME SB127 400 Monel Sheets
ASTM B127 400 Monel Plates ASME SB127 400 Monel Plates
Werkstoff Nr. 2.4360 Monel Plates UNS N04400 Monel Plates

Pricelist of Monel 400 Sheets & Plates

Jaydeep Steels is one of the most competitive suppliers of pipes and tubes from India. Our prices for Monel 400 Sheets & Plates are very competitive.

Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Jaydeep Steels maintains a stock of all standard items and can export them at the best price for 400 Monel Sheets & Plates.

400 Monel Sheets & Plates - Industries & Applications

Our Monel 400 Sheets & Plates are used in a wide range of applications and various industries. Below are a few of them:

  • Gas Processing Industries
  • Petrochemical Industries
  • Power Generation Industries
  • Food Processing Industries
  • Chemical Industries
  • Oil & Gas Industries
  • Fertilizers Industries
  • Sugar Industries

Available Stock of 400 Monel Sheets & Plates

We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for Monel 400 Sheets & Plates.

Click to send your requirement.

How to Buy Monel 400 Sheets & Plates

Jaydeep Steels is a leading stockist, distributor, and supplier of 400 Monel Sheets & Plates from India. We maintain huge stocks and you can easily buy 400 Monel Sheets & Plates and other forms of Pipe Fittings at one of the best prices. Please use the contact button or click here to send us your requirement to Buy 400 Monel Sheets & Plates from Jaydeep Steels.

400 Monel Sheets & Plates Exporter:

Exporting Monel 400 Sheets & Plates to Singapore, Malaysia, Hongkong, Thailand, Indonesia, Taiwan. Other countries includes  Afghanistan, Albania, Andorra, Austria, Bahrain, Bangladesh, Bhutan, Brunei, Belarus, Belgium, Bulgaria, Cambodia, China, Cyprus, Croatia, Czech Republic, Denmark, Estonia, Egypt, Finland, France, Germany, Greece, Georgia, Hungary, Iceland, Ireland, Italy,  Iran, Iraq, Israel, Japan, Jordan, Kazakhstan, Kuwait, Kyrgyzstan, Lebanon, Latvia, Latin America, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Maldives, Mongolia, Myanmar (Burma), Nepal, North Korea, Netherlands, Norway, Oman, Poland, Portugal, Pakistan, Palestine, Philippines, Qatar, Russia, Romania, Russia, San Marino, Serbia and Montenegro, Slovakia, Slovenia, Spain, Sweden, Switzerland, Saudi Arabia,  South Korea, South Africa, Sri Lanka, Syria,  Tanzania, Tajikistan, Thailand, Turkey, Turkmenistan, Ukraine, United Kingdom, United Arab Emirates (UAE), Uzbekistan, Vietnam, Yemen.
