Aluminum Lithium Alloy 2099 Manufacturer
Certified Aluminum 2099 Lithium Alloy Exporter, Aluminum Alloy 2099 T8E67 Dealers, Aluminium Alloy 2099 T83 Manufacturer, AL 2099 Round Bar Supplier, AL 2099 Flat Bar, AL 2099 Rectangular Bar Stockists in India
Aluminium 2099 Alloy Round Bars Stockholder, Aluminium 2099 Alloy Flat Bars & Rods, AL 2099 Cold Drawn Bars & Rods, AL 2099 Hot Rolled (HR) Bars & Rods, AL 2099 Cold Rolled (CR) Bars & Rods, Aluminium 2099 Square Bars & Rods Manufacturer, Supplier
Jaydeep Steels is acknowledged to be one of the leading manufacturers and supplier of Aluminum 2099 Alloy. SHP 2099 Ultimate is a high-strength aluminium lithium alloy ideal for use in environments requiring low density, high stiffness, superior damage tolerance and excellent corrosion resistance. The alloy was developed specifically for use in motorsport, aerospace and high strength applications.
Lithium additions increase the strength and modulus of aluminium alloys while lowering denseness. Alloy 2099 extrusions are available in three tempers from 0.5 to 3.00 inch in T83 and 160mm to 200mm in T8 temper. This material grade offers high strength and excellent corrosion resistance with moderate fracture toughness.
2099 Aluminum Sheet Exporter, 2099 Aluminum Plate, 2099 Aluminum Extrusion, 2099 Aluminum Extrusion angles, 2099 Aluminum Billet, 2099 Aluminum Ingot Wholesaler in India
The corrosion resistance of Alloy 2099 is much better than 7075-T6511 and 2024-T3511 with both the T8E67 and T83 tempers receiving EA (mild exfoliation) or better exfoliation ratings compared to the conventional alloys ED (very severe intergranular corrosion). Stress-corrosion cracking performance is also much improved.
2099 aluminium lithium alloy is a low-density material with high stiffness. With superior damage tolerance and excellent corrosion resistance, the alloy offers excellent weldability. Applications of Aluminum Alloy 22099 are High strength applications, Aerospace, Statically and dynamically loaded fuselage structures, Lower wing stringers, Stiffness dominated designs, etc. Contact us today and avail a quick quote today!
Aluminum 2099 Alloys Chemical Composition
| Element | WT. (%) |
|---|---|
| Cu | 2.4 – 3.0 |
| Li | 1.6 – 2.0 |
| Zn | 0.4 – 1.0 |
| Mg | 0.10 – 0.50 |
| Mn | 0.10 – 0.50 |
| Zr | 0.05 – 0.12 |
| Ti | 0.10 max |
| Fe | 0.07 max |
| Si | 0.05 max |
Mechanical Properties of Aluminum Alloy 2099
| Properties | 2099-T8E67 | 2099-T83 | ||
|---|---|---|---|---|
| Thickness | 0.50-0.999* | 1.00-2-5* | 1.00–2.5″ | |
| Tensile Strength, ksi (Mpa) | L
LT |
77 (530)
74 (510) |
81 (560)
76 (525) |
83 (595)
75 (520) |
| Yield Strength, ksi (Mpa) | L
LT |
70 (485)
62 (430) |
76 (525)
70 (485) |
78 (505)
68 (470) |
| Compressive Yield Strength | L
LT |
69 (475)
64 (440) |
75 (520)
75 (520) |
78 (540)
70 (485) |
| Elongation, % | L | 10 | 9 | 9 |
| Tension Modulus, Msi (Gpa) | 11.3 (78) | |||
| Density | 0.095 (2.63) |
Physical Properties of Aluminum Alloy 2099
| Properties | Metric | Imperial |
|---|---|---|
| Density | 2.6-2.8 g/cm3 | 0.0939- 0.101 lb/in3 |
| Melting point | 510°C | 950°F |
Aluminum 2099 Alloys Other Product Forms
Jaydeep Steels stocks a wide range of materials and grades. Below are a list of all standard aluminum alloy 2099 other product forms we stock.
- 2099 Aluminum Sheet
- 2099 Aluminum Plate
- 2099 Aluminum Extrusion
- 2099 Aluminum Extrusion angles
- 2099 Aluminum Billet
