SA 516 Gr. 60 Plates
ASTM A516 Grade 60 Carbon Steel Plates, ASTM A516 Grade 60 Boiler Quality Steel Plates, ASTM A516 GR. 60 Pressure Vessels Plate, ASTM A516 Grade 60 Boiler Plate Suppliers in India
ASME SA516 GR. 60 Carbon Steel Plate, ASTM A516 Gr 60 Boiler Quality Steel Plates, ASTM A516 Gr 60 Hot Rolled Steel ASTM A516 Gr 60 Plates, ASTM A516 Plates for Moderate and Lower Temperature Service Stockholders in India
Are you in search of best quality plates that you can use for your industrial applications easily and for a long time? If yes, then your search ends here as ASTM A 516 GR. 60 Plates are the right option for you. We have gathered a huge customer base in this domain by presenting a comprehensive range of SA 516 Gr. 60 Boiler Plates. The offered plates have SA516 grade 60 dual certified HIC NACE TM0284 hydrogen induced cracking.
SA 516 Gr. 60 Plates
ASME SA-516 Steel Plates, also known carbon steel plates that used for pressure vessel plates and moderate or lower temperature service. A516 grade 60 steel plates are intended primarily for service in welded pressure vessels where improved notch toughness is important. Apart from this, clients can get the plates from us at industry leading rates. Contact us today!
SA 516 Gr. 60 Plates Specification
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement |
| Impact tested | -52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
SA 516 Gr. 60 Plates Available Sizes in Ready Stock
| 6 x 2000 x 12000 | 8 x 2500 x 12000 | 10 x 2000 x 12000 | 10 x 2500 x 12000 | 10 x 2500 x 6000 |
| 12 x 2000 x 12000 | 12 x 2500 x 12000 | 14 x 2000 x 12000 | 14 x 2000 x 5400 | 14 x 2500 x 12000 |
| 16 x 2000 x 12000 | 16 x 2500 x 12000 | 18 x 2500 x 12000 | 20 x 2500 x 12000 | 22 x 2000 x 11500 |
| 25 x 2500 x 12000 | 25 x 2500 x 9000 | 32 x 2500 x 6000 | 32 x 2500 x 3000 | 36 x 2500 x 6000 |
| 40 x 2500 x 6000 | 40 x 2500 x 7000 | 75 x 2500 x 4100 | 90 x 2500 x 6800 | 90 x 1500 x 2700 |
Equivalent Grades of SA 516 Gr. 60 Plates
| Grade | British Standard | European Norm | ASTM/ASME | DIN |
| Gr. 60 | BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
Chemical Composition of SA 516 Gr. 60 Plates
| Grade | C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| Gr. 60 | 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
Mechanical Properties of SA 516 Gr. 60 Plates
| Grade | Tensile strength | Yield strength | Elongation min, % |
| Gr. 60 | 415-550 Mpa | 250 Mpa | 21 |
Price List of SA 516 Gr. 60 Plates
Jaydeep Steels is one of the most competitive suppliers of Plates from India. Our prices for SA 516 Gr. 60 Plates are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Jaydeep Steels maintains a stock of all standard items and can export them at best price for SA 516 Gr. 60 Plates.
SA 516 Gr. 60 Plates - Industries & Applications
Our Sheets & Plates are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Available Stock of SA 516 Gr. 60 Plates
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for SA 516 Gr. 60 Plates.
How to Buy SA 516 Gr. 60 Plates
Jaydeep Steels is a leading stockist, distributor, and supplier of SA 516 Gr. 60 Plates from India. We maintain huge stocks and you can easily buy Welten SA 516 Gr. 60 Plates and another form of 60 Plates at one of the best prices. Please use the contact button or click here to send us your requirement to Buy SA 516 Gr. 60 Plates from Jaydeep Steels.
SA 516 Gr. 60 Plates Exporter:
Exporting SA 516 Gr. 60 Plates to Singapore, Malaysia, Hongkong, Thailand, Indonesia, Taiwan. Other countries includes Afghanistan, Albania, Andorra, Austria, Bahrain, Bangladesh, Bhutan, Brunei, Belarus, Belgium, Bulgaria, Cambodia, China, Cyprus, Croatia, Czech Republic, Denmark, Estonia, Egypt, Finland, France, Germany, Greece, Georgia, Hungary, Iceland, Ireland, Italy, Iran, Iraq, Israel, Japan, Jordan, Kazakhstan, Kuwait, Kyrgyzstan, Lebanon, Latvia, Latin America, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Maldives, Mongolia, Myanmar (Burma), Nepal, North Korea, Netherlands, Norway, Oman, Poland, Portugal, Pakistan, Palestine, Philippines, Qatar, Russia, Romania, Russia, San Marino, Serbia and Montenegro, Slovakia, Slovenia, Spain, Sweden, Switzerland, Saudi Arabia, South Korea, South Africa, Sri Lanka, Syria, Tanzania, Tajikistan, Thailand, Turkey, Turkmenistan, Ukraine, United Kingdom, United Arab Emirates (UAE), Uzbekistan, Vietnam, Yemen.
